Hella RokLUME 280 N LED Light

R0,00

The RokLUME 280 N driving light was developed for heavy-duty applications with particularly high illumination requirements. The enormous illumination power provides more than double the light compared to a xenon-driving light and therefore turns night into day.

Specifications

Work lamp Auxiliary headlamp
Operating voltage Multi-voltage (9-32 V)
Rated voltage 12 V/ 24 V
Current consumption ø 3.85 A (12 V)
ø 1.86 A (24 V)
Power consumption ø 46 W (12 V)
ø 45 W (24 V)
max. 50 W
Light output up to 5,000 lm
Light source LED
Colour temperature 5,000 K
Material Housing: die-cast aluminium with NanoSafe non-stick / easy to clean surface coating
Cover lens: hard coated plastic
Weight up to 1,430 g
Temperature range -40 °C to + 85 °C (overheat protected)
Protection class IP 6K9K, IP 6K8
Type approval ECE-R10, UKCA, RCM ECE-R149 Class B, ECE-R10, UKCA, RCM
EMC protection CISPR 25
Salt spray resistance 1,200 h as per DIN EN ISO 9227
Mounting Upright, pendant and horizontal
Connection DEUTSCH DT 2 pin connector, DEUTSCH DT counterpart included
Manufactured in Austria



SKU: N/A Categories: ,

All-round talent in its second generation: The HELLA RokLUME 280N Generation 2 work lamp provides the best possible light in harsh mining environments.

With its very high light output of up to 5,000 lumens, the lamp offers drivers of heavy-duty vehicles enhanced visibility to detect hazards well in advance.

The RokLUME 280N Generation 2 is available in six illumination options. In addition, variants with coloured cover lenses in amber and green are available, which are designed to combat reflective environments such as fog, falling snow or dust-laden air.

The variants with ZEROGLARE illumination feature a new reflector and a refined optical lighting system that creates a sharp horizontal cut-off at 0° to direct the light onto the ground in front of the vehicle. This prevents oncoming drivers from being dazzled.

The centred, robust heavy duty bracket allows three mounting positions: upright, pendant and horizontal. This ensures that the work lamp meets the high-vibration requirements of mining vehicles.

Technical Data

Cover lens colour Illumination Part number
Clear Close-range illumination 1GA-995706-501
Long-range illumination 1GA-995706-511
ZEROGLARE illumination 1GA-995706-521
Pencil beam illumination 1GA-995706-531
Tunnel flood illumination 1GA-995706-551
Diffused Diffuse flood illumination 1GA-995706-541
Green Close-range illumination 1GA-995-706-571
Long-range illumination 1GA-995706-581
ZEROGLARE illumination 1GA-995706-591
Pencil beam illumination 1GA-995706-601
Amber Close-range illumination 1GA-995706-631
Long-range illumination 1GA-995706-641
ZEROGLARE illumination 1GA-995706-651
Pencil beam illumination 1GA-995706-661



Additional information

Cover lens colour

Clear, Diffused, Green, Amber

Illumination

Close-Range, Long-Range, Pencil Beam, ZERO GLARE, Tunnel Flood, Diffused flood
